Tires

20.5-16 steel wire tyres (front two and back two)

Overall dimension

6500mm*2350mm*2900mm

6500mm*2350mm*2900mm

Wheelbase

2500mm

Overall quality

6000KG

Driving form

Four-wheel drive

Maximum speed

35Km

Maximum Climbing Capacity

35°

Minimum turning radius

2355mm

Minimum Ground Clearance

350mm

Engine

Yunnei 490 turbocharged

云内490增压

Rated power

65(kW)

Transmission

Model

ZL265 torque converter

Gear

Four in, four out, double high and low speed

Common oil filling quantity

Fuel tank capacity

100L

Total capacity of hydraulic system

100L

Oil volume

16L

Hydraulic system

Reducer

Borrego 230B closed type

Pump

Rui Zhi Chen Cheng R140/80

Motors

Zhenjiang power 160

Water supply system

Water tank volume

600L

Water supply method

Time relay

Mixing and unloading

Geometric capacity of mixing tank

2.6m³

Rotating speed of mixing tank

17 revolutions/min

Concrete output (m³/tank)

1.6m³
